IFE 4T61, 61" Bypass Log Grapple & Rotator: Universal Log, Scrap, Stone Grapple!

IFE 4T61 HEAVY DUTY, Universal 61" Pinching Or Bypass 4-Tine Log & Stone Grapple With HR3607 Hydraulic Rotator & Half Hanger: Suitable For Brush, Logs, Scrap, Stone, RR Ties, Waste - Most Anything!

• Rotator Turns 360° CONTINUOUSLY in Both Directions - Clockwise & Counter Clockwise!
• Maximum Working Load: 15,400lb's.
• Suitable for Most Applications on 8 to 12 Ton Machines.
• Moderate Applications Would Be Primarily Vertical Lifting of Material.
• In Rigorous Skidding Applications, The 11,000lb's Working Capacity Can Quickly Be Surpassed. For Those Applications, Consider Upgrading To The HR36011, or HR36016 Rotators.
• Max Working Pressure is 3629psi.
• Half Hanger is Included & Shown in Last Photo:
• Half Hanger Weight: 17lb's.
• Overall Width of Rotators Mounting Boss: 5-1/8".
• Inside Width of Mounting Boss: 3-1/8".
• Rotators Boss Pin Hole is 15/16" Diameter.
• Rotator Weight: 100lb's.
• This Listing is For The Grapple & Rotator Only - All Other Machines & Attaching Systems Are For Reference Only!
• Specifications are based on manufacturer provided data & subject to change.

• Maximum Opening: 61".
• Minimum Opening: 4".
• Maximum Lift Capacity: 6600lb's.
• Height (grade to top of Grapple) in Open Position: 30".
• Height (grade to top of Grapple) in Closed Position: 21".
• Overall Width of Claw: 18".
• Maximum Working Pressure: 3625psi.
• Grapple Weight: 474lb's.
• Specifications are based on manufacturer provided data & subject to change.
